Model NT3 Series
Page 6 midlandusa.com
BATTERY INSTALLATION
Your NAUTICO3 radio operates with either 4 AA alkaline batteries or
an optional NiMH battery pack. The belt clip should be removed (see
below) to ease installation or removal of the batteries.
To install the batteries:
1. With the back of the radio facing you, remove the belt clip (see
diagram below) for easy access, then remove the Battery Cover
by pulling down the Battery Cover Latch and lifting up the Battery
Cover from the radio.
2. Insert 4 AA batteries observing the polarity as shown. Installing the
batteries incorrectly will prevent the radio from operating or may
damage the radio.
3. Return the Battery Cover by sliding it up on the radio and push up
the Battery Cover Latch until it locks into place. Replace the belt
clip, making sure it locks into place.
BATTERY
COMPARTMENT
One Battery inserted
in this slot
BATTERY COVER
BATTERY COVER
LATCH
INSTALLING THE BELT CLIP
To install the BELT CLIP, slide the clip down into
the slot on the back of the radio until the BELT
CLIP LATCH clicks. To remove the BELT CLIP,
press the LOCK TAB up, then gently pull the belt
clip up toward the top of the radio.
BELT CLIP
LOCK TAB
BELT CLIP
LATCH
