CT710 Instruction Guide | 29
Technical Specification
General
Frequency range
144-146MHz / 430-440MHz
Operative temperature -20° +55°C
Operating voltage 7.4V 1600mAh
Operating mode mono band / dual band
Dimensions 95(H) x 55(L) 31(D) mm
Weight 230gr (antenna included)
Antenna impedance 50Ω
Duty cycle 5/5/90
Transmitter
Frequency stability
±2.5ppm
Output power VHF: 5W / UHF: 4W
Max frequency deviation ±5KHz
Audio distortion ≤ 3%
Adjacent Channel Power within European legal terms
Spurious Radiation within European legal terms
Occupied Bandwidth within European legal terms
Receiver
RF sensitivity
<0.2μV
Audio distortion ≤ 3%
Audio response 300Hz ÷ 3KHz
Adjacent Channel Selectivity within European legal terms
Intermodulation Rejection within European legal terms
Blocking within European legal terms
Specifications are subject to change without notice.
