Mody Pumps MSPG Series User Manual
Page 9
PARTS LIST
MODY MSPG2 GRINDER
ITEM
DESCRIPTION
QTY
MATERIAL
1
LATCH BOLT (FAST LOCK) (SMALL)
2
stainless steel 304
2
LOWER BEARING HOUSING
1
cast iron GG25
3
WASHER SPACER
2
TEFLON
4
IMPELLER CG2
1
ductile iron GGG40
5
WEAR PLATE
1
cast iron GG25
6
BEARING LOWER
1
3307B.2ZTNG
7
ΚΕΥ
1
stainless steel
8
GRINDER DISC (stationary)
1
stainless steel
9
GRINDER ( rotary)
1
stainless steel
10
GASKET
1
11
VOLUTE
1
cast iron GG25
12
LOWER COOLING FLANGE
1
cast iron GG25
13
UPPER BEARING HOUSING
1
cast iron GG25
14
SHAFT ROTOR PX2-1
1
stainless steel 304
14a
SHAFT ROTOR PX2-2
1
stainless steel 304
15
STATOR HOUSING MSP2-1
1
cast iron GG25
15a
STATOR HOUSING MSP2-2
1
cast iron GG25
16
MOISTURE SENSOR
1
aluminioum/rubber
17
COOLING JACKET
1
cast iron GG25
18
MOTOR COVER
1
cast iron GG25
19
COOLAND TUBE
1
steel
20
ROTOR BODY
1
siemens
21
BASI KLEMAS
1
22
WIRE CORE
1
siemens
23
MSP2 SEAL CATRIDGE ASSEMBLY
1
24
COOLANT HOSE ASSEMBLY
2
rubber/stainless steel
25
CABLE SEAL compl. PG29(16)
for 7x1,5mm²
1
25a
CABLE SEAL compl. PG29(19)
for 7x2,5mm²
26
HANDLE
1
stainless steel 304
27
ADAPTER
1
ductile iron GGG40
28
O-RING
1
NBR
29
O-RING
1
NBR
30
O-RING
1
NBR
31
O-RING
1
NBR
32
PLUG
2
A2
33
KEY
1
stainless steel 304
33
SCREW
2
stainless steel 304
34
SCREW
1
stainless steel 304
35
SCREW
1
stainless steel 304
36
O-RING
1
stainless steel 304
37
NUT
4
stainless steel 304
39
BEARING UPPER
1
6305DDU C3
40
BOLT
2
stainless steel 304
41
SCREW
1
stainless steel 304
42
BOLT
4
stainless steel 304
3/4/2008
Page 1 of 2
