Hardware setup – Asus Apollo PL133 Chipset Socket 370 Motherboard CUVL-VM User Manual
Page 27
ASUS CUVL-VM User’s Manual
27
3. HARDWARE SETUP
Connectors
3. H/W SETUP
7) Game/MIDI Connector (Gold 15-pin GAME_AUDIO) (optional)
This connector supports a joystick or a game pad for playing games, and MIDI
devices for playing or editing audio files.
8) Audio Connectors (Three 1/8” AUDIO) (optional)
The Line Out (lime) connects a headphone or speakers. The Line In (light blue)
connects a tape players or other audio sources. The Mic (pink) connects a
microphone.
Joystick/MIDI (15-pin female)
Mic
Line In
Line Out
1/8" Stereo Audio Connectors
