27
Machine Operation
To Turn on Machine
Turn key to operate position ( I )
To Turn on Vacuum
Lower squeegee into operate position, vacuum motor will turn on automatically.
To Turn on Brush Motor
Move brush lift pedal from the “home” (down) position to the operating position (up). Depress the operator bail handle. Brush motor will
turn on and assist to propel the machine forward.
To Turn on Cleaning Solution
Move solution lever from closed (down) position up to the desired flow position.
NOTE: When you no longer want solution or stop the machine for an extended period of time, you must move the solution lever
back to the closed (down) position. Otherwise, solution will continue to flow onto the floor.
To Charge Batteries
When the battery / fault gauge reaches the red zone the batteries need to be recharged. Take the machine to a well ventilated area,
unwind the battery charger power cord from the electrical box cover and plug into an appropriate power source. After approximately 10
seconds the battery charge status indicator will turn on.
For Wet batteries only: Check the battery water levels before each use, refill as needed with distilled water.
Caution: DO NOT OVERFILL. Fill water 1/4 “ - 1/2” above the separators. Failure to maintain the batteries may result in
battery failures.
WARNING: Charging batteries generates explosive gasses. Do not charge batteries when open flames or sparks are present. Do
not smoke. Charge the batteries in a well-ventilated area .
Hour Meter (Optional)
Hour meter will automatically record operating time of the brush motor.
Solution Solenoid (Optional)
Water solenoid will operate when the brush motor is turned on. The solution lever must be moved to the desired operating position, but
does not need to be moved to the closed position when stopping for brief periods.
