26
OPERATING INSTRUCTIONS
FILLING THE X17
Remove clear solution cover lid from front of machine, or use the supplied faucet fill hose, by
pulling hose out and holding rubber inlet against faucet. Fill solution tank with desired amount of
warm water and add liquid cleaning chemical, Minuteman Extraction Shampoo order #902163.
(See instructions on container for proper dilutions.) DO NOT USE powdered cleaning chemicals.
Powders are unlikely to dissolve thoroughly, resulting in clogging the inline solution strainer and
other fittings. This can reduce or stop solution flow to the pump and spray jets.
Carpet should be thoroughly vacuumed and obstacles relocated before beginning the cleaning
cycle. Heavy traffic lane areas should be pre-treated or spotted with Minuteman Pre-Treat order
#902183 for best results.
TO BEGIN CLEANING:
Maximum Water Temperature
Operating Instructions
1. Always work away from the cord.
2. Machine operates by pulling backwards over carpet.
3. The recovery dome lid, page 12, item B, should be properly seated on Recovery Tank, item C, for proper vacuum recovery.
4. See page 14, Control Panel Switch Identifications:
Normal Cleaning Mode
1.
Turn on vacuum switch (C).
2. Turn on brush switch (B).
3. Turn on the solution pump (D) to position 1.
4. Adjust brush pressure at rear of machine, until brush pressure gauge reads in green zone.
5. Solution pump should be turned off by either using the momentary bail, item A,or flip the switch spray jet to the center
position, item D, 6" before the end of each cleaning pass.
