How to take the Machine into operation
12
Assembly
When being supplied to you, the E 17e is packed in a cardboard box. The floor consists of a wooden platform
where the machine is fixed by means of plastic straps.
Open the box from its bottom side and remove it by pulling upwards. After detaching the plastic wraps, you now
can follow the below 4 instructions.
I
Owner’s personnel is not allowed to open the machine.
Preparing for use
1. Tilt the body of the machine after removing rubber caps & allen
screws(on both sides) in order to Gain access to the inside of the
machine.
Rubber cap
& screw
2. The brush motor is fastened to its guide ways by a screw in order to
prevent unwanted movement during transport. Remove this screw and
check for the up-and-down movement of brush motor. Also remove the tie
bolt indicated in the picture.
Screw
Tie bolt
