Minuteman Kleen Sweep 27 - Manual (Page 6)

2.1 Controls
1. Pressure adjustment knob for Side Brush
Used for setting of the side brush. The side brush may touch the floor
only by its one third section, so as to throw the swept matter into the
machine.
The castor wheel is to keep the pre-set working height of the side
brush.
2. Pressure adjustment knob for Main Brush
Used for setting of the main brush pressure. The pressure must be set
so as to assure perfect cleaning operation.
2.0 Operation
1
2
3
3. Knobs
Used to secure the handle to the machine or to reposition it.
4. Main Brush Pressure Reading Scale
Indicates the pressure at which the main brush has been set.
Setting must be performed as described below :
Set the main brush by turning the knob clock-wise to increase the pressure, at this position the
scale should read ‘5’ .
Starting with this setting, the main brush pressure can be increased to meet the requirement.
(As the brush wears out)
Turn the knob in counter-clockwise direction to reduce the main brush pressure according to
the requirement.
Excess pressure will cause unnecessary wear of the brush and increased load for the operator.
4
4
