Dimensions (mm) specifications – Milton Roy Mixing HELISEM RANGE FRF SERIES User Manual
Page 2
Type
A B
E
F
C
0041S
370
110
160
130
9
0051S
370
110
160
130
9
0061S
370
110
160
130
9
0081S
370
110
160
165
11
0101S
385
130
200
165
11
0102S
385
130
200
165
11
0121S
385
180
250
215
13.5
0141S
385
180
250
215
13.5
0142S
385
180
250
215
13.5
0162S
385
180
250
215
13.5
0203S
414
180
250
215
13.5
1252S
463
230
300
265
14
2302S
522
250
350
300
18
3362S
550
250
350
300
18
Ref:
MRM8212201-06/09-Rev02-All rights re
ser
ved for modification without prior notice-non binding informations
DIMENSIONS (MM)
SPECIFICATIONS
Type
Rated power
Rotation speed
Maximum height
Propeller Diameter
Propeller flowrate Weight
Axial load
Torque
(kW)
(rpm)
(mm) H
(mm) D
(m
3
/h)
(Kg)
(DaN)
(DaNm)
0041S
0.37
70.3
1500
400
155
24
2
10
0051S
0.37
56.3
1500
500
240
26
3
13
0061S
0.37
49.3
1500
600
365
27
4
14
0081S
0.37
35.2
2000
800
620
42
6
20
0101S
0.37
28.7
2000
1000
1000
49
10
25
0102S
0.37
28.7
3200
1000
1000
54
10
25
0121S
0.37
23.7
2600
1200
1350
68
15
31
0141S
0.37
19.2
1800
1400
1750
61
17
38
0142S
0.37
19.2
3000
1400
1750
69
17
38
0162S
0.37
16.7
3100
1600
2360
77
22
42
0203S
0.37
14.9
4100
2000
4055
141
43
47
1252S
0.55
11
3500
2500
5900
211
57
96
2302S
0.75
9.8
4000
3000
9000
316
93
146
3362S
1.1
8
4500
3600
12750
662
131
263
