Milton Roy Mixing HELISEM RANGE FRF SERIES - Manual

HELISEM
®
RANGE
FR SERIES MIXERS
General characteristics
• HELISEM ® range, well dedicated to open tanks, is
appropriate for the treatment of urban and
industrial water
• Agitators type VLA, VRG and VRT, are adapted to
current applications
• Types FR are exclusively reserved for flocculation
• The shape of the propeller and the very slow
speed allow an optimal flocculation
Capacities
• From 1 to 400 m 3 approximately
Operating conditions
• Atmospheric pressure
• Temperature up to 90°C
Composition
• 1 motor
• 1 speed reducer
• 1 shaft
• 1 blade impeller R type
TYPEFRF
Open tanks from 1 to 400 m 3 – Atmospheric pressure – Temperature up to 90°C
Application
• Flocculation
Options :
• Variable speed drive
• Base plate
• Second impeller
• ATEX mixer
• Special motors (60 Hz)
Material :
• Stainless steel 316 L
• PU painting : RAL 1018 for driving device
(other materials : contact us)
