HELISEM
®
RANGE
VT1000 SERIES MIXERS
General Characteristics
•
Direct drive motor or speed reducer drive
•
Lantern with radial bearing
•
Flange connection to the vessel ND 150 NP 10
•
Lower shaft fitted with impeller adjustable in position
•
Power from 0.37 to 1.5 kW
•
High rotation speed (1500 rpm) and slow speed
(160 or 260 rpm)
Capacities
•
From 0.05 to approx.2 m
3
Operating conditions
•
Pressure from vacuum 0 to 5 bar g.
(depending on seal device)
•
Temperature : up to 120°C
Main applications
•
Chemicals
•
End-products manufacturing
•
Homogenization
•
Dissolving
•
Solid suspension
•
Storage
Construction materials
•
Stainless steel 316L
•
Painting PU : RAL 1018 (on drive system)
(please consult for any other material)
Electrical characteristics
•
230/400 volt three-phase
•
50 Hz
•
IP 55
(please consult us for any other voltage
and frequency)
Options
(depending on mixer type)
•
Special motors (60 Hz)
•
Variable speed
•
additional impeller
Robust construction
•
Low maintenance conception
•
Guiding bearing
•
Possible rotation during discharge
Operational limits
•
Maximum viscosity of 100 mPas
•
Density < = 1.1
•
Not recommended for gaz dispersion !
SERIE VT1000
Closed tanks from 0.5 to 2 m
3
- Sealing systems - Pressure from 0 to 5 bars - Temperatures up to 120°C
•
ATEX mixer
•
ADF Motors
