Dimensions (mm) specifications, Please consult us for any other request – Milton Roy Mixing HELISEM RANGE VDA SERIES User Manual
Page 2
Type
A
B
C
E
F
1210S
250
110
9
160
130
2210S
250
110
9
160
130
2110S
285
130
11
200
165
2520S
285
130
11
200
165
4310S
300
130
11
200
165
4630S
320
130
11
200
165
Please consult us for any other request.
DIMENSIONS (MM)
SPECIFICATIONS
Type
Rated power
Rotation speed
Maximum height
Propeller Diameter
Propeller Flowrate
Weight
Torque
(kW)
(rpm)
(mm) H
(mm) D
(m
3
/h)
(Kg)
(Nm)
1210S
0.25
1500
1000
80
32
10
3
2210S
0.25
1500
1000
128
104
10
3
2110S
0.25
750
1000
128
52
12
6
2520S
0.75
1500
1250
128
104
14
9
4310S
0.37
750
1000
160
101
19
10
4630S
1.5
1500
1500
160
203
20
18
The minimum height of the liquid at the top of the impeller might be 300 mm.
It is necessary to respect a distance of 150 mm between the flange and the level of the liquid.
