164-110-350 Max Machinery, Inc.
Page 5
WIRING & CONTROL DIAGRAM
(S4)
4-20mA or 1-5 mA Range
(S6)
0-10V Range
(S5)
0-2V Range
(S7)
Input multiplier
& Current range select
(S9)
Frequency range
(S10)
Waveform select
(S8)
DC/Frequency switch
Hysteresis Adjust
Discontinued
