164-110-350 Max Machinery, Inc. Page 3
The Model 164 has separate 0-10V, 0-2V and 4-20mA outputs, with individual Range, Span
and Zero adjustments. The 0-2V output has an associated 5V supply connection designed to
power a DVM. The 4-20mA output can be switched to provide l-5mA.
The Damping control is a three pole low pass filter, designed to even out flow signal
variations caused by pump noise or flow meter design.
Specifications
Analog Input Range . . . . . . . . . . . . . . . . . . . . . . . 0 to 30V
Frequency Input Range
Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30mV to 20V P-P
Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 to 10 KHz
Waveform . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pulse, Square or Sine
Hysteresis (Sine Wave) . . . . . . . . . . . . . . . . . . 0 to 500 mV
Minimum Input Frequency
(For Full Scale Output) . . . . . . . . . . . . . . . . . . 30 Hz Pulse or Sine Wave,
15 Hz Square
Damping Filter Time Constant . . . . . . . . . . . . . . . 70 mS to 20 Seconds
Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 to 10 V @ 5 mA
0 to 2 V for DVM
4 to 20 mA (or 1 to 5 mA)
@ 0 to 24 V
Linearity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ± 0.05% of FS
Temperature Coefficient . . . . . . . . . . . . . . . . . . . . ± 0.1%/10°C of FS
Recommended Operating Temperature . . . . . . . . 30°F to 120°F
Size (PCA only) . . . . . . . . . . . . . . . . . . . . . . . . . . 7 3/8"L X 5 1/2"W X 2"H
Power Requirements . . . . . . . . . . . . . . . . . . . . . . . 110/220 VAC @ 15 W
SPECIFICATIONS
Discontinued
