Page 22

Select NEXT MENU:

LAST RECOVERED QTY

TANK CHARGING

AIR PURGE

Select DATA AND CONFIGURAT.:

CONFIGURATION

SERVICES

PREVIOUS MENU

Select DATA.
The following screen will be displayed:

Ref avail

XX.XX lb

Tank temper

XX.X°F

Tank Press

XX psi

ACp

xx psi

NOTE: TP: xx psi will be ﬂashing
- Ref avail.: quantity of refrigerant available in the storage tank.
- Tank temp.: temperature of the refrigerant storage tank.
- Tp: pressure of refrigerant tank.
- ACp: pressure in the external air conditioning system.

PASSWORD PROTECTION

A password can be used to prevent the machine from being used. Once a password is activated, it will be needed every time the operator makes an
attempt to activate any command from the MAIN screen. To use the password feature,

AUTOMATIC PROCEDURE

ASSISTED PROCEDURE

Ref avail X,XX lb
