Magnum Venus Plastech CFH-4000 User Manual
Page 15
15
1
CFH-4000-AI
2
HEATER ASSY
PARTS LIST
ASSY - DOUBLE STACK CFH HEATER CFH-4000-AIDS
PART NO.
ITEM
QTY
DESCRIPTION
2
60950-1
1
MOUNTING BRACKET
3
COL-CLMP
2
COLUMN CLAMP
4
F-HB-06C-40-GR5
4
HEX BLOT
5
F-HB-06C-20
8
HEX BOLT
6
F-HB-06C-20
12
HEX NUT
7
F-SW-06
8
LOCK WASHER
8
HAW-08
3FT
RESIN HOSE
9
390H-08248
8
SWEDGE ON HOSE FITTING
10
2103-8-10
2
PARKER ELBOW - HOSE TO PIPE
11
033T-8-8
2
PARKER HOSE TEE
1
BRUSH ANTI SEIZE ON CFH-3079 TIE RODS
TO FILL THE THREADS. TORQUE THE
F-HN-08F-GR8 NUTS TO 60 FT/LBS
1
