Page 21
Patriot Metering Pump Manual PAT-CP-1530
Rev. 03/2013
Page | 21
Parts Drawings:
PAT-CP-1530
METERING PUMP ASSEMBLY
PAT-CP-1530-ADH
METERING PUMP ASSEMBLY – ADHESIVE
PAT-CP-1530-S
METERING PUMP ASSEMBLY – SIPHON FEED
PAT-CP-1530-SK
METERING PUMP SEAL KIT
PAT-CP-1530-ADH-SK METERING PUMP SEAL KIT – ADHESIVE
