TL – 4016 MEMORY CONTROL CONSOLE
Revision 1.4
OWNERS MANUAL
02/20/2005
www.lightronics.com
Lightronics
Inc.
509
Central
Drive
Virginia
Beach,
VA
23454
TEL
757
486
3588
SPECIFICATIONS
Total Channels
32 or 16 depending on mode
Operating modes 16 channels x 2 manual scenes
32
channels
x
1
manual
scene
16
channels
+
16
recorded
scenes
Scene memory
16 scenes total
Chase
2 programmable 23 step chases
Control protocol
LMX-128 (multiplex)
USITT
DMX-512
is
optional
Output connector
3 pin XLR connector
5
pin
XLR
for
DMX-512
Compatibility
Multiplex
protocol
compatible
with
other
multiplexed
systems
Power
input
18VAC
or
+15VDC
Optional
external
power
supply
Dimensions
16.25"W X 9.25"H X 2.5"H
Weight 6.7
Pounds
Other features of the TL-4016 include: grand master fader, split dipless crossfader, momentary "bump" buttons,
and blackout control. Two 23 step chases may be run simultaneously for complex patterns. Chase rate is set by
tapping the rate button at the desired rate. Scenes and chases stored in the unit are not lost when the unit is
turned off
INSTALLATION
The TL-4016 control console should be kept away from moisture and direct sources of heat.
LMX CONNECTIONS: Connect the unit to a Lightronics (or compatible) dimmer using a multiplex control cable
with 3 pin XLR connectors. The TL-4016 is powered by the dimmer which it is connected to. It may also be
powered via an optional external power supply. The unit will operate with dimmers in both the NSI/SUNN and
Lightronics modes. All dimmers connected to the unit MUST be in the SAME mode.
DMX CONNECTIONS: Connect the unit to a DMX dimmer using a control cable with 5 pin XLR connectors. The
DMX-512 connection does NOT provide console power therefore an external power supply (provided with units
having DMX option) must be used.
LMX-128 Connector Wiring
(3 PIN FEMALE XLR)
DMX-512 Connector Wiring
(5 PIN FEMALE XLR)
PIN #
SIGNAL NAME
1 Common
2
Phantom power from dimmers
Normally +15VDC
3
LMX-128 multiplex signal
PIN #
SIGNAL NAME
1 Common
2
DMX data -
3
DMX data +
4 Not
Used
5 Not
Used
CONTROLS AND INDICATORS
X Faders:
Control individual channel levels for channels 1 – 16.
Y Faders:
Control level of scenes or individual channels depending on current operating mode.
Cross Fader:
Fades between X and Y row faders.
Bump Buttons:
Activates associated channels at full intensity while pressed.
Chase Select:
Turns chases on and off.
Chase Rate:
Press three or more times at desired rate to set chase speed.
Y Mode Indicators:
Indicate current operating mode of Y faders.
Y Mode Button:
Selects operating mode of Y faders.
Blackout Button:
Turns on and off console output from all scenes, channels and chases.
Blackout Indicator:
Lighted when blackout is active.
Grand Master:
Adjusts output level of all console functions.
Record Button:
Records scenes and chase patterns.
Record Indicator:
Flashes when chase or scene recording is active.
