1. Push MENU 3 times. The LCD will appear as shown:
2. Push SELECT. Then push MENU. The LCD will appear as shown: The bottom
display row shows the currently selected pattern. The pattern "4Ch Seq" is
shown as an example.
3. Use the UP and DOWN arrow buttons to scroll through the available chase
patterns. Push SELECT when the desired pattern appears.
Note:
Remember that this action does not activate the chase pattern. This action selects which pattern will be
run when activated by the remote switch function.
The available patterns are:
4 CHANNEL SEQUENCE 8 CHANNEL SEQUENCE
4 CHANNEL BUILD 12 CHANNEL SEQUENCE
6 CHANNEL SEQUENCE RANDOM
6 CHANNEL BUILD PROGRAMMABLE
CONTROLLING CHASER CHARACTERISTICS
You can control seven characteristics of a chase pattern. These controls are described as follows:
Chase Rate
The duration of each chase step (.25 - 999.75 Sec.).
Default = 1 Sec.
Chase Fade Rate
The time for each step to reach maximum intensity (0 - 100% of step time).
Default = 100%
Chase Intensity
The overall brightness of the chase (0 - 100%)
Default = 100%
Chase Steps
The maximum number of steps in the chase (1 - 32)
Default = 4
Chase Bounce
Causes reversal at the end of each sequence (Ignored during RANDOM).
Default = Off
Continuous /Single
Enables/Disables a "one shot" chase occurrence (Ignored during RANDOM).
Default = Continuous
Activate Chase at power up
Enables chase to begin automatically when dimmer is turned on. **
Default = Off
** Overrides remote switch setting
The default setting is the factory set value.
All of these characteristics can be set via the RD-122 menu system. See the diagram STRUCTURE OF MENU
SYSTEM for a complete layout of menu system operation.
MENU
Chase# ¦
4Ch Seq
