The computer has four easy-to-read status indicators on the upper-right above the keyboard, and four on the
front panel.
The power, battery and wireless communication status indicators are visible even when the LCD display is
closed.
#
Item
Description
1
Wireless LAN bay
Houses the computer’s wireless LAN.
2
Battery lock
Locks the battery in place.
3
Battery release latch
Releases the battery for removal.
4
Battery bay
Houses the computer’s battery pack.
5
Cooling fan
Helps keep the computer cool.
Note: Do not cover or obstruct the opening
of the fan.
6
Memory and hard disk
bay
Houses the computer’s main memory and
hard disk (secured by a screw).
#
Item
Description
Note
#
Icon
Item
Description
