Installation and Quick Start Guide
Rio Rancho, NM
13
Channel Subscriptions
Each input to a breakout box occupies a Dante chan-
nel. The total Dante channel usage, however, will
vary depending upon the number of multiple receiver
subscriptions.
The numbers in the diagrams are used to indicate the
number of Dante channels being used.
SYSTEM EXAMPLE - SIGNAL FLOW AND ROUTING
DANTE CHANNELS AT CROSSPOINTS
TRANSMITTERS
BOB A 1 BOB A 2 BOB A 3 BOB A 4 BOB A 5 BOB A 6 BOB A 7 BOB A 8 BOB B 1 BOB B 2 BOB B 3 BOB B 4 BOB B 5 BOB B 6 BOB B 7 BOB B 8
RECEIVERS
BOB A 1
1
BOB A 2
1
BOB A 3
1
BOB A 4
2
BOB A 5
2
BOB A 6
3
BOB A 7
4
BOB A 8
5
BOB B 1
BOB B
6
2
BOB B
7
3
BOB B
8
4
BOB B
9
5
BOB B
9
6
BOB B
0
1
7
BOB B
0
1
8
Multiple Receiver Subscriptions
In the lower diagram, multiple receiver subscriptions reduce the
number of Dante channels used in the system. In this example, inputs
1 through 5 on BOB B are routed to outputs 1 through 8 on BOB A,
using only 5 Dante channels. Inputs 4 through 8 on BOB A are routed to
outputs 2 through 8 on BOB B, using 5 Dante channels.
SYSTEM EXAMPLE - SIGNAL FLOW AND ROUTING
DANTE CHANNELS AT CROSSPOINTS
TRANSMITTERS
BOB A 1 BOB A 2 BOB A 3 BOB A 4 BOB A 5 BOB A 6 BOB A 7 BOB A 8 BOB B 1 BOB B 2 BOB B 3 BOB B 4 BOB B 5 BOB B 6 BOB B 7 BOB B 8
RECEIVERS
BOB A 1
1
BOB A 2
2
BOB A 3
3
BOB A 4
4
BOB A 5
5
BOB A 6
6
BOB A 7
7
BOB A 8
8
BOB B 1
9
BOB B 2
10
BOB B
1
1
3
BOB B
2
1
4
BOB B
3
1
5
BOB B
4
1
6
BOB B
5
1
7
BOB B
6
1
8
1:1 Subscriptions
In the upper diagram, 1:1 subscriptions use a Dante channel
for each input to output signal path, so the total number of
audio inputs and outputs is equal to the Dante channels used.
