Lectrosonics RCWTEL User Manual
Rcw-tel, Wired remote controller for the telephone hybrid

RCW-TEL
Wired Remote Controller
for the Telephone Hybrid
Feature Highlights
• Transparent operation with respect to the
TH3, i.e. front panel controls are replicated
on the RCW-TEL
• Connected directly to the
Remote Control
Port
(DB-9) of the TH3
• Remote functions include connect/
disconnect, privacy, and receive volume
up/down
• LED indicators for the remote functions
• Works with telephone or codec interface, or
use two RCW-TELs to control both
The RCW-TEL provides the main operating con
trols for the TH3 hybrid in a remote location.
The circuit board is mounted to a single-gang
wall plate. Soft touch switches and highly
visible LEDs provide simple, intuitive operation
and instant recognition of the status of the TH3.
LECTROSONICS
RCW-TEL
TELECONFERENCE
PRIVACY
CONNECT
VOLUME
UP
DOWN
T M
