INTRODUCTION
Thank you for selecting the Lectrosonics Professional Series wireless microphone system. This system
represents well over 10 years of manufacturing experience in wireless microphones, and almost 70
years of design experience.
The UR190 UHF receiver design is the result of surveying the needs of professional video producers,
ENG cameramen and many others in the broadcast and pro video industry. Hundreds of conversations
with dealers and end-users developed the final parameters for the design.
The UR190 receiver is a fixed frequency design that eliminates the need to "tune" or adjust the receiver
every time it is used. This is the preferred design for a number of reasons, among them simplicity of
operation, no adjustments in "high pressure" situations, and interference rejection by design rather than
by trying to "tune" it out.
The UR190 miniature receiver was designed by professionals for outstanding performance and
flexibility, while preserving ease of operation. It is compatible with all Lectrosonics high band
transmitters. The UR190 receiver represents one of the best values in wireless, regardless of price.
TABLE OF CONTENTS
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
GENERAL TECHNICAL DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . 2
CONTROLS AND FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
RECEIVER FRONT PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
RECEIVER REAR PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
ANTENNA USE AND PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
OPERATING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
INDICATOR QUICK REFERENCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
UR190 REPLACEMENT PARTS AND ACCESSORIES . . . . . . . . . . . . . . . 9
SERVICE AND REPAIR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
RETURNING UNITS FOR REPAIR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
SPECIFICATIONS AND FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back cover
