PHABRIX®
®
PHABRIX® Sx
A
Generator/Analyzer/Monitor + AES
• 3 IN 1, GENERATOR / ANALYZER / MONITOR
• 3G-SDI, HD-SDI, SD-SDI, AES
• HIGH QUALITY 16:9 PICTURE MONITOR
• SUPERIOR EASE OF USE
• 32+ VIDEO TEST SIGNALS STANDARD
• TEXT AND LOGO IDENT
• 16 CHANNEL EMBEDDED AUDIO
• AUTO GENLOCK BI/TRI/SDI CROSS LOCK
• 16 CHANNEL AUDIO METERING
• WAVEFORM MONITOR
• VECTORSCOPE
• RUGGED RELIABILITY
• ETHERNET BASED REMOTE OPERATION
• BATTERY + AC POWER SUPPLY
FEATURE HIGHLIGHTS
PHABRIX ® SxA: Announcing the
WORLD's FIRST 3G-SDI, HD-SDI,
and SD-SDI portable video test signal
generator, monitor and analyzer
With its impressive 4.3" 16:9 TFT monitor and easy to control menu
buttons, the PHABRIX ® SxA has been designed specifically for the
professional broadcast engineer.
The PHABRIX ® SxA supports 3G-SDI, HD-SDI, SD-SDI video plus
AES audio testing and monitoring - a world's first for such a product
and important in an industry where technology quickly advances.
Configured with a full range of test patterns, both static and
animated, the SxA is ideal for studio, OB, and lab environments
operating from the internal battery or the included AC adaptor.
Auto Bi-level, Tri-level and SDI genlock with cross lock capability.
Combined audio features including support for 16 channels of
embedded audio complete the suite of functions.
With built-in USB and Ethernet connectivity for remote operation, the
Phabrix ® SxA sets a new standard in portable video/audio signal test
generation and monitoring.
