Laurel Electronics LTE: Ethernet & 4-20 mA Output Transmitter for Duty Cycle Input User Manual
Page 4
LAUREL
ELECTRONICS INC.
, 3183-G Airway Ave., Costa Mesa, CA 92626, USA • Tel 714-434-6131 • www.laurels.com 4
Ordering Guide
Create a model a model number in this format: LTE80FR
Transmitter Type LTE Laureate 4-20 mA & Ethernet Transmitter
Main Board
8 Extended Main Board (required for duty cycle function)
Power
0 Isolated 85-264 Vac
1 Isolated 12-32 Vac or 10-48 Vdc
2 Power over Ethernet (PoE)
Input Type
FR Dual-Channel Frequency
