Laurel Electronics LTE: Ethernet & 4-20 mA Output Transmitter for Duty Cycle Input User Manual
Page 3
LAUREL
ELECTRONICS INC.
, 3183-G Airway Ave., Costa Mesa, CA 92626, USA • Tel 714-434-6131 • www.laurels.com 3
Pinout
Mechanical
Application Example
Duty Cycle and Elapsed Time of a Laser
Duty cycle can be used to indicate the On time
of a pulsed laser in relation to total time. Laureate
counters and transmitters can also measure
elapsed time, the number of pulses, average
width in µs, the number of pulses, and total
energy applied.
