Impulse WebOP-3070T User Manual

Webop-3070t, Features, Specifications

background image

Intelligent Operator Panels

Operator Panels

Features

WebOP-3070T

Specifications

General

ƒ

Certification

CE, BSMI, CCC, UL, FCC Class A

ƒ

Dimensions (WxHxD) 203.4 x 150 x 43.7 mm (8.01" x 5.91" x 1.72")

ƒ

Cut-out Dimensions

192 x 138.5 mm (7.56" x 5.45")

ƒ

OS Support

Microsoft

®

Windows CE 6.0

ƒ

Power Input

24V

DC

±10%

ƒ

Power Consumption

7W (Typical)

ƒ

Enclosure Housing

PC + ABS

ƒ

Mounting

Panel

ƒ

Weight (Net)

1 Kg (2.20 lbs)

System Hardware

ƒ

CPU

RISC 32 bits, 600 MHz (ARM

®

Cortex™-A8)

ƒ

Backup Memory

FRAM 128KB

ƒ

Memory

DDR2 256MB on board

ƒ

Storage

512MB on board SLC type

ƒ

Power-On LED

Yes

Communication Interface

ƒ

COM1

RS-232/422/485 (DB9 Male)

ƒ

COM2

RS-422/485 (Terminal Plug 4-Pin)

ƒ

COM3

RS-485 (Terminal Plug 2-Pin)

ƒ

CAN

Terminal Plug 2-Pin

ƒ

Ethernet (RJ45)

10/100-BaseT

ƒ

I/Os

USB Client

USB 2.0 Client x 1

USB Host

USB 2.0 Host x 1

Micro-SD Slot

Yes

Audio

1 Line-out / 1 Mic-in

LCD Display

ƒ

Display Type

WVGA TFT LCD

ƒ

Display Size

7"

ƒ

Max. Resolution

800 x 480

ƒ

Max. Colors

64K

ƒ

Luminance (cd/m

2

)

500

ƒ

Viewing Angle (H/V)

140/120

ƒ

Backlight Life

LED, 50,000 hrs

ƒ

Dimming

Adjustable by touch panel

ƒ

Contrast Ratio

700:1

Touchscreen

ƒ

Lifespan

36 million touches at 8mm-diameter finger point
through silicone rubber bearing at least 250g 2 times
per second.

ƒ

Light

Transmission Above 80%

ƒ

Resolution

Linearity

ƒ

Type

5-wire, analog resistive

Environment

ƒ

Operating Temperature -20 ~ 60°C (-4 ~ 140°F)

ƒ

Storage Temperature -30 ~ 70°C (-22 ~ 158°F)

ƒ

Humidity

10 ~ 90% RH @ 40°C, non-condensing

ƒ

Ingress Protection

Front panel: IP66

ƒ

Vibration Protection

Operating, radom vibration 1 Grms (5 ~ 500 Hz)

ƒ RISC 32 bits TI ARM

®

Cortex™-A8 processor

ƒ Various LCD sizes (7", 10.1", 12", 15")

ƒ Full line LED BL TFT LCD with 50K life time

ƒ Embedded Microsoft

®

WinCE 6.0 OS

ƒ Support WebOP Designer HMI Runtime development tool

ƒ Backup Memory FRAM in 128KB(64 words) without battery concern

ƒ Power & Terminal I/O ports isolation protection

ƒ -20°C ~ 60°C wide operating temperature range

ƒ Support CANopen library registered by CiA 301 V4.02

ƒ RS-422/RS-485/CAN terminal I/O ports support Termination Resistor 120

Ω

ƒ Front panel IP66 compliant

ƒ Die-cast aluminum alloy front bezel

ƒ Level 4 ESD protection (Air:15KV / Contact:8KV)

ƒ Industrial Control Equipment - UL 508 certification

7" WVGA Cortex™ - A8

Operator Panel with

Wide Operating Temperature Range

Introduction

With brand-new ID design, the WebOP-3070T provides stringent standards required in the automation market. Advantech offers the WebOP-3070T with Cortex™-A8 processor which
consumes minimum power without sacrificing performance. The WebOP-3000T supports a variety of LCD sizes from 4.3” to 15” for different applications involving the use of PLCs,
motion/thermal controllers, inverters and sensors. It’s also provided with a wide operating temperature range to fulfill the requirements of harsh environments. The built-in Microsoft

®

WinCE 6.0 OS platform which bundles WebOP Designer lets the WebOP-3070T becomes a control HMI solution for flexible system integration.

NEW

Date updated: 22-Oct-2013
