Impulse W10ID3S-IPH1 - Manual

W10ID3S-IPH1
10.1" Panel PC
(Intel Atom D2550+NM10 Platform)
R
Specifications
Power Specifications :
Power Input
Power Consumption 12V DC-IN Power input
32W (typ.)(Max.backlight & high CPU load) :
:
Accessories :
External Power Supply 36W w/power cord
Modularized Construction
Note: All Specifications are subject to change without prior notice!
SBC Board
Panel
Storage (HDD)
Touch/Glass
(Optional)
Metal Frame Housing
Back Cover
Panel Mount(6 mm front bezel)
BOTTOM VIEW
FRONT VIEW
SIDE VIEW BACK VIEW
Operating Temperature
Operating Humidity
Environment Considerations :
:
: 0 deg.C to 45deg.C
30% to 90% (non condensing)
Front bezel
(5mm)
Rev. Reasons Revised Date
Revised Date:04-11-2012
Fanless design Mechanical Design
System :
Serial Ports
Ethernet
VGA
Power Input
USB Ports
:
:
:
:
:
Input / Output :
CPU
LAN
Memory Slot
System Chipset
IDE/SATA
:
:
:
:
:
Panel Spec :
Size/Type
Resolutions
Brightness
Viewing Angle
Max. Colors
Contrast Ratio
:
:
:
:
:
:
10.1" TFT (Wide screen)
1024x600
250cd/m (typ.)
500 : 1(typ.)
-70~70(H);-50~60(V)
256K(6bit)
Jan-18-12
Mar-03-12 First Release
Revise Spec 1.0
1.1
Cut out dimension(239*170mm)
1.
2.
3.
4. DC-IN Power Jack
VGA Out
USB
RS232/422/485
1 2 4 3 5 6 7
5.
6.
7. RJ-45
Dimming Knob
RS-232
1 x SODIMM, Max 4GB DDR3 800/1066
Intel NM10
2 x SATA
Intel Atom D2550 1.86GHz Processor R
R
Dual Broadcom BCM57780 GbE controller
1 x RS232/ 1 x RS232/422/485
2 x USB
2 x RJ45-10/100/1000
1 x VGA
1 x DC-IN Power Jack
Default setting:RS232
Order Options :
OS :
: Mechanical Open Frame
Panel Mount (6mm bezel)
IP65 (6mm bezel)
Touch 4 Wires Resistive(Optional)
:
RAM : SODIMM DDR3
800/1066
Windows 7 embedded /
Windows XP embedded
(Optional)
Expansion Slot :
1 x Mini PCIe slot (for wireless module)
1 x Mini PCIe slot (for SATA SSD)
1.2 Spec change Apr-11-12
