* All specifications and photos are subject to change without notice. 441
1. Power switch (ATX)
2. Terminal block for DC power input
or 3. Screw conn. w/ AC power adapter
4. USB 2.0 x 2
5. VGA
6. COM 1 (RS-232/422/485)
7. COM 2 (RS-232)
8. Ethernet x 2
9. USB 2.0 x 2
10. Audio (Line-out)
GOT5120T-832
12.1" XGA/SVGA TFT Fanless Touch Panel
Computer with Intel ® Atom™ Processor
N2600
● 12.1" XGA/SVGA color TFT LCD display with LED backlight
● Fanless design with Intel ® Atom™ processor N2600 1.6 GHz
● Supports WLAN module & internal antenna
● Supports 2 Giga LAN, 4 USB & 2 COM ports
● Easy for expansion: PCIe Mini card
● Supports panel mount, wall mount, VESA arm, desktop stand
(optional)
● Supports RFID (optional)/speaker (optional)
Introduction Specifications
The GOT5120T-832 is a 12.1" Intel ® Atom™-based fanless touch panel computer. In
response to market demand, this panel computer is a cost effective solution. It adopts a
modern, super sleek and fanless design and is equipped with a 12.1" TFT LCD as well as
Intel ® Atom™ processor N2600 1.6 GHz. For wireless network connection, the GOT5120T-
832 offers a mini card slot. By just plugging in the mini card WLAN card, customers can
have instant access to wireless LAN/GPRS/GSM/3G environments. Besides, it provides
two types of power input. One is DC power input (10~30VDC) with terminal block
connector. The other is AC power adapter with screw type connector.
Super slim & ultra light design
The GOT5120T-832 is a super slim touch panel computer for space-limited environment
with its thickness of 52mm and weight of 2.4 kg only, which make it installed everywhere.
Built-in internal WLAN antenna
The GOT5120T-832 provides a mini card slot and a built-in WLAN antenna for wireless
network connections. By simply plugging in the wireless LAN card, customers can use the
GOT5120T-832 in a wireless LAN/GPRS/ GSM/3G environments.
Excellent thermal solution: aluminum back chassis
With Axiomtek's patent for plastic plus aluminum mechanism design, the GOT5120T-832
can dissipate the heat easily and keep the system operation stable.
Front Bezel IP65, NEMA 4 rugged protection, plastic front bezel
LCD Panel Display Type 12.1" XGA/SVGA TFT LCD with LED
backlight
Brightness (cd/m 2 ) 500 nits (XGA)
450 nits (SVGA)
Resolution 1024 x 768 (XGA)
800 x 600 (SVGA)
Viewing Angel (H/V) 160°/140°
Main System CPU Intel ® Atom™ processor N2600
1.6 GHz
Chipset Intel ® NM10
System
Memory
1 x 204-pin DDR3 SO-DIMM max.
up to 2 GB
BIOS AMI UEFI BIOS
Storage 1 x 2.5" SATA HDD
1 x CompactFlash™
Watchdog Timer 255 levels, 0~255 sec.
Onboard Graphics Integrated in Intel ® GFX
Features
Side view
Desktop stand
Fanless Low Power DualView
1
2 3
4 5 6 7 8 10 9
DDR3
DDR3 DDR3
