Features
Specifications
Ru
gg
ed H
M
I T
ouc
h P
ane
l S
olu
tio
ns
17” SXGA (1280 x 1024) TFT LCD Display ■ ■
Intel® Celeron® 827E Processor, Fanless Cooling System ■ ■
IP-65 Aluminum Die Cast Front Bezel ■ ■
Two Easy Access Front USB Ports ■ ■
Power Input Protection: ■ ■
Over-Voltage Protection
Low-Voltage Protection
Reverse Protection
17” Rugged Fanless Touch Panel Computer With Intel® Celeron® 827E Processor, 2G RAM
System
Processor Onboard Intel® Celeron® 827E, 1.4 GHz
Memory DDR3 SODIMM x 2, Max. 8GB
LCD/CRT Controller Integrated in Intel® QM67
Ethernet 10/100/1000Base-TX, RJ-45 x 2
I/O Port
RS-232 x 2, USB2.0 x 6 (2 on front; 4 on rear),
Line-in/Line-out, VGA x 1
Storage Disk Drive 2.5" SATA Hard Disk Drive/ CFast™ Slot (Internal)
Expansion Slot PCIe Mini Card x 1
OS support Windows® XP, Windows® 7, Linux kernel 2.6.X or above
Mechanical
Construction IP-65/ NEMA4 for aluminum die Cast Front bezel & Aluminum chassis
Mounting Panel/ Desktop/ VESA100/ Rack/ Wall
Dimension 16.54” x 14.09” x 3.82” (420mm x 358mm x 97mm)
Carton Dimension 26.02” x 8.11” x 19.53” (661mm x 206mm x 496mm)
Gross Weight 23.1 lb (10.5 kg)
Net Weight 17.82lb (8.1 Kg)
Environmental
Operating Temperature -4°F ~ 140°F (-20°C ~ 60°C)
Storage Temperature -4°F ~ 158°F (-20°C ~ 70°C)
Storage Humidity 10%~95% @40°C; non-condensing
Vibration 3 g rms/ 5~500 Hz/ Random operation (HDD)
Shock 15 G peak acceleration (11 msec. Duration)
EMC CE/FCC Class A
Power Supply
DC input
9~30V DC input, w/3-pin terminal block: over-voltage protection; low-voltage
protection; reverse protection
LCD
Display type 17" TFT-LCD
Max Resolution 1280 x 1024
Max. Colors 16.7M colors
Luminance 350 cd/m 2
Viewing Angle 170°(H)/160°(V)
Back Light LED
Back Light MTBF (hours) 50,000
Touchscreen
Type 5-wire resistive
Light Transmission 80%
Lifetime (times) 35 Million activations
AHP-2176
USB x 2
Brightness -
DC-in
USB x 4
COM2
VGA x 1
Power Switch
COM3
LAN x 2
Audio
Brightness +
LCD On/Off
