Impulse R19IC7T-IPM1 - Manual

Specifications
Power Specifications :
Power Input
Power Consumption 12V DC IN (Lockable Power Jack)
173W (typ.)(Max.backlight & high CPU load) :
:
Operating Temperature
Operating Humidity
Environment Considerations :
:
:
Mechanical Design
Front bezel
(Optional)
Inverter
SBC Board
Panel
Storage (HDD/CF)
Touch/Glass
(Optional)
Metal Frame Housing
Back Cover
FRONT VIEW SIDE VIEW BACK VIEW
BOTTOM VIEW
Note: All Specifications are subject to change without prior notice!
0 deg.C to 50 deg.C
30% to 90% (non condensing)
IP65 (8 mm front bezel)
2 3 4 5 6 7 8 9 10 11 1
1.
2.
3.
4.
5.
6. 7.
8.
9.
10.
11.
12.
RS-232 Conn.(Optional)
Audio Jack
DVI (Optional)
USB
LAN
VGA RS-232 Conn.
PS/2
DC-IN Lockable Power Jack
Brightness Adjustment Knob
Power On Button
Power Reset Button
R19IC7T-IPM1
19" Panel PC ( ) Intel® Core™ i7-620M/i5-520M
Revised Date:04/28/2011
Serial Ports
USB Ports
Keyboard / Mouse
Ethernet
VGA
:
:
:
:
:
Input / Output :
Default setting:RS232
2 x RS232, 1 x RS232/422/485
4 x USB
2 x PS/2
2 x RJ45-10/100/1000Mbps
1 x VGA (female)
Panel Spec :
Size/Type
Resolutions
Brightness
Contrast Ratio
Viewing Angles
Max Colors
:
:
:
:
:
:
19" TFT
1280 x 1024
2 400 cd/m (typ.)
1000 : 1(typ.)
-85~85(H);-80~80(V)
16.7M (8 bits/colors)
RAM
OS
DVD
Storage :
:
:
:
Order Options :
(A customized housing is needed if you
have demands of SAW/IR/IT/SC touch)
3.5" HDD 250G
SO-DIMM DDR3 1066/800
Windows XPE (Optional)
Windows XPPE (Optional)
Windows 7 (Optional)
Linux (Optional)
Yes
Mechanical
Touch
Open Frame
Panel Mount(8 mm bezel)
IP65(8 mm bezel)
5 Wires Resistive(Optional)
:
:
Rev. Reasons Revised Date
1.0 First release Apr-28-11
Fully Integrated I/O
Dimensions
Mechanical design
Accessori es :
Externa l Adapter : 110~230V Ac-in power adapter
12
Measurements shown in mm
Tolerance of all dimensions is shown as follow 0~30 mm ± 0.1 mm,
30~50 mm ± 0.15 mm, 50~120 mm ± 0.2 mm, above 120 mm ± 0.25 mm
Note: this is a simplified drawing and some components are not marked in detail.
Please contact our sales representative if you need further product information.
*
*
*
OS BSP / Driver Support :
Support Windows 7 / Windows XP Embedded /
Windows XPP Embedded / Linux 2.6
System :
CPU
Memory
System Chipset
Storage
LAN
Audio Codec
:
:
:
:
:
:
Intel® Core™ i7-620M/i5-520M Processor
(2.66GHz / 2.4GHz)
2 x SO-DIMM, Max 8GB DDR3 1066/800
Intel® HM55 Chipset
2 x SATA II (Default 3.5" 250G)
Dual Broadcom BCM57780 GbE
Realtek ALC886 HD Audio Codec
Expansion Slot :
1 x PCI-E(x16), 2 x Mini PCI-E
