Marine Displays and Computers
MPC-2240 Series
Introduction
24 inch fanless panel computer with Intel Celeron 1047UE 1.4 GHz
processor, NMEA 0183, RS-232/422/485 serial ports, Gigabit LAN ports,
USB 2.0 ports, SSD trays, dual AC/DC power inputs
The MPC-2240 series of panel computers features advanced Intel
processors—3rd generation Ivy Bridge Core or Celeron—matched to 4
GB of system memory, delivering a reliable, high-performance platform
of wide versatility for use in industrial marine environments. With its
RS-232/422/485 serial, NMEA 0183, and Gigabit Ethernet LAN ports,
the MPC- 2240 panel computer supports a wide variety of serial- and
marine-specific interfaces alongside high speed IT communications, all
with native network redundancy.
The MPC-2240 series comes with a range of standard display
enhancements useful in industrial environments (including 0 to 100%
full range dimming, 178°/178° wide viewing angles, optional optical
bonding, and/or multi-touch screen), as well as Moxa’s innovative
SavvyTouch display controls.
The MPC-2240 series of panel computers are compliant with several
industrial marine standards, such as IEC 60945 4
th , IEC 61174,
IEC 61162, DNV2.4, and IACS E10, verifying their resilient durability
in marine operations. An optional IP65-rated unibody shell provides
strong additional protection against the harsh conditions found
in marine environments. The MPC-2240 delivers a rugged, type
approved, high performance and user friendly panel computer perfect
for ECDIS navigation systems and other marine IBS applications.
Appearance
›
24 inch panel computer
›
Color calibrated for ECDIS compliance
›
Fanless design
›
SavvyTouch display controls
›
3rd Generation Intel ® Core ™ or Celeron ® processor (Default:
Celeron ® 1047UE, 1.40 GHz with Intel ® HD Graphics)
›
Built-in NMEA 0183 and software selectable RS-232/422/485
interfaces (DI/DO and LPT available on request)
›
Dual AC/DC power supply units
›
Optically bonded and touch panel models available on request
AC Power Input
DC Power
Input
USB 2.0
Host x 4
RS-232/422/485 Port x 2
DVI-D/VGA
Output
NMEA 0183 Port x 8
Gigabit LAN Port x 2
PS/2 Mouse/Keyboard
Line in/out
2.5” SSD Tray x 2 SavvyTouch Display
Control Button x 5
Panel
Grounding Connector
