Dimension
Unit: mm
FOX-121
Optional Accessories
STAND-FOXS0 •
Desktop Stand
1757910004 •
AC Adapter 100W
1702031803 •
Power Cord 3P-250V
9761F12100 •
GPRS/GPS Kit
9761F12101 •
WiFi Kit, 802.11 b/g
Accessories in Packing
1700090208 •
COM (D-SUB) Cable with Waterproof M12 Connector
(FOX series)
1709080251 •
Two USB Y Cables with Waterproof M12 Connector
(FOX series)
M990FOX001 •
3-pin Water-proof Cap Connector for DC-in or Audio
Line-out Port (FOX series)
P990FOX001 •
Water-proof Cap Connector for LAN Port of FOX
series (RJ-45-compliance)
Ordering Information
Part Number
Display
Type
Max
Resolution
Luminance
View
Angle
Backlight
MTBF (Hours)
CPU LAN USB RS-232
RS-
485/422/232
Storage RAM Display Expansion Mounting Power Temp. Touch Other
TF-FOX-121
HTT-A1-1011 12.1" TFT-
LCD
1024 x 768 500 cd/m 2
160(H),
160(V)
50,000
Intel® Atom™
N270, 1.6GHz
1 2 1 1
CF Kit x 1
SATA-HDD Kit x 1
1G — Mini PCI x 1
VESA
75/100 DC
9~30V -20°C~55°C
( w/o air ) 5 Resistive
Touch
—
TF-FOX-121
HTT-A2-1011 12.1" TFT-
LCD
1024 x 768 500 cd/m 2
160(H),
160(V)
50,000
Intel® Atom™
N270, 1.6GHz
1 2 1 1
CF Kit x 1
SATA-HDD Kit x 1
1G — Mini PCI x 1
VESA
75/100 DC
9~30V -20°C~55°C
( w/o air ) 5 Resistive
Touch
1 Antenna
TF-FOX-121
HTT-A3-1011 12.1" TFT-
LCD
1024 x 768 500 cd/m 2
160(H),
160(V)
50,000
Intel® Atom™
N270, 1.6GHz
1 2 1 1
CF Kit x 1
SATA-HDD Kit x 1
1G — Mini PCI x 1
VESA
75/100 DC
9~30V -20°C~55°C
( w/o air ) 5 Resistive
Touch
2 Antenna
TF-FOX-121
STT-A1-1011 12.1" TFT-
LCD
1024 x 768 1000 cd/m 2
160(H),
120(V)
60,000
Intel® Atom™
N270, 1.6GHz
1 2 1 1
CF Kit x 1
SATA-HDD Kit x 1
1G — Mini PCI x 1
VESA
75/100 DC
9~30V -20°C~55°C
( w/o air ) 5 Resistive
Touch
—
TF-FOX-121
STT-A2-1011 12.1" TFT-
LCD
1024 x 768 1000 cd/m 2
160(H),
120(V)
60,000
Intel® Atom™
N270, 1.6GHz
1 2 1 1
CF Kit x 1
SATA-HDD Kit x 1
1G — Mini PCI x 1
VESA
75/100 DC
9~30V -20°C~55°C
( w/o air ) 5 Resistive
Touch
1 Antenna
TF-FOX-121
STT-A3-1011 12.1" TFT-
LCD
1024 x 768 1000 cd/m 2
160(H),
120(V)
60,000
Intel® Atom™
N270, 1.6GHz
1 2 1 1
CF Kit x 1
SATA-HDD Kit x 1
1G — Mini PCI x 1
VESA
75/100 DC
9~30V -20°C~55°C
( w/o air ) 5 Resistive
Touch
2 Antenna
Packing List
FOX-121 Touch Panel PC •
USB Cable with Water Proof Connector •
COM Cables with Water Proof Connectors •
Waterproof Connector for DC–in (Female) •
Waterproof Connector for LAN (Optional) •
Waterproof Connector for Audio-Line-Out (Optional) •
Easy Stand •
CD-ROM for Manual (in PDF Format) and Drivers •
FOX-121 •
