2.6.5 Automatic Relay Activation Time Zone Programming (Up to 4)
Factory setting in step 3 is 0 (Time zones are OFF).
This program sequence sets up time zones to automatically activate and deactivate relays. Up to four (4) time zone can be
programmed, each of which can be assigned to the desired relay(s). These time zones can be independently turned ON or
OFF after they have been programmed.
1. Press
*
3 5 and enter the MASTER CODE. [
*
3 5 _ _ _ _ (beep)]
2. Enter a time zone number (1, 2, 3 or 4), then press
*
. [ _
*
(beep)]
3. Press 0
*
to turn the time zone OFF, OR press 1
*
to turn the time zone ON. [ _
*
(beep)] You can terminate
here (Go to step 11 to finish) if you have previously programmed the time zone and only ON / OFF is desired.
4. Enter the beginning hour (01 to 12) and minutes (01 to 59), then press
*
. [ _ _ _ _
*
(beep)]
5. Press 0
*
for AM OR press 1
*
for PM. [ _
*
(beep)]
6. Enter the ending hour (01 to 12) and minutes (01 to 59), then press
*
. [ _ _ _ _
*
(beep)]
7. Press 0
*
for AM OR press 1
*
for PM. [ _
*
(beep)]
8. Enter the days of the week that the auto relay time zone is to be active, then press
*
. [ _ _ _ _ _ _ _
*
(beep)]
Sun =1, Mon = 2, Tue = 3, Wed = 4, Thu = 5, Fri = 6, Sat = 7.
You can enter up to 7 numbers here (1-7) but all 7 spaces do not have to be populated with numbers. For
example, for the auto relay time zone to be active only on Saturdays and Sundays, enter 1 7
*
. The order of the
numbers is not important; 17 is the same as 71.
9. Enter the relay number(s) that the time zone will apply to, then press
*
. [ _ _
*
(beep)]
You can enter a single relay number (1 or 2) or both relay numbers (1 and 2 together - 12).
10. Repeat steps 2 through 9 to program the other time zones (up to 4).
11. Press 0 # TOGETHER to end. [0 # (beeeeeep)]
2.6.6 Access Code Time Zone Programming (Up to 4)
Factory setting in step 3 is 0 (Time Zones are OFF).
This programming sequence sets up time zones (up to 4) that can be applied to the “Access Code Programming (Time
Zone Restricted)” programmed in section 2.5.2 into the 1812. These time zones can be turned ON or OFF once they have
been programmed.
1. Press
*
3 6 and enter the MASTER CODE. [
*
3 6 _ _ _ _ (beep)]
2. Enter a time zone number (3, 4, 5 or 6), then press
*
. [ _
*
(beep)]
Do not use 0, 1 or 2 for time zone numbers. These are already used; 0 = always deny,
1 = 24/7 access for Relay 1 ONLY ; 2 = 24/7 access for Relay 2 ONLY.
3. Press 0
*
to turn the time zone OFF, OR press 1
*
to turn the time zone ON. [ _
*
(beep)]
You can terminate here (Go to step 11 to finish) if you have previously programmed the time zone schedule and
only ON / OFF is desired.
4. Enter the beginning hour (01 to 12) and minutes (01 to 59), then press
*
. [ _ _ _ _
*
(beep)]
5. Press 0
*
for AM OR press 1
*
for PM. [ _
*
(beep)]
6. Enter the ending hour (01 to 12) and minutes (01 to 59), then press
*
. [ _ _ _ _
*
(beep)]
7. Press 0
*
for AM OR press 1
*
for PM. [ _
*
(beep)]
8. Enter the days of the week that the time zone is to be active, then press
*
. [ _ _ _ _ _ _ _
*
(beep)]
Sun =1, Mon = 2, Tue = 3, Wed = 4, Thu = 5, Fri = 6, Sat = 7.
You can enter up to 7 numbers here (1-7) but all 7 spaces do not have to be populated with numbers.
For example, for the time zone to be active only on Saturdays and Sundays, enter 1 7
*
. The order of
the numbers is not important; 17 is the same as 71.
9. Enter the relay number(s) that the time zone will apply to, then press
*
. [ _ _
*
(beep)]
You can enter a single relay number (1 or 2) or both relay numbers (1 and 2 together - 12).
10. Repeat steps 2 through 9 to program the other time zones (up to 4).
11. Press 0 # TOGETHER to end. [0 # (beeeeeep)]
