BILL OF MATERIAL FOR: RAM 30
45 50-304 120/240 Intelligate Transformer 1
46 50-337 1/2" x 1-1/2" Hex Head Bolt 1
47 50-339 1" x 2" Plastic Cap 2
48 50-401 10 Ga Heavy Duty Metal Chassis 1
49 50-402 Board Lexan Glass Cover 1
50 50-403 Polyethylene Cover 1
51 50-404 3/4" x 10" Limit Switch Shaft 1
52 50-405 40A27 Sprocket 1
53 50-406 3/4" Limit Switch Cam 2
54 50-407 1/2" x 1" Cast Iron Pulley 2
55 50-408 6" Aluminum Pulley 1
56 50-409 4L V Belt #250 1
57 50-419 1/4" x 1 1/2" x 10" Ext. Gate Bracket 1
58 50-529 #6 x 2" Machine Screw 2
59 50-511 120 VAC Double Outlet 1
60 50-526 #6 x 1/4" Machine Screw 2
61 50-539 5/16" Socket Head Screw 9
62 50-546 Internal Gate Bracket Swing Arm 1
63 50-559 Access Door Frame 1
64 50-560 Access Door 1
65 50-563 1 1/2" x 1 1/2" x 3/4" Sq. Pivot 1
66 50-564 1/2" x 1 1/2" Iron Pulley 1
67 50-565 5/16" x 1 1/2" Knob 1
68 50-566 5/16" x 1/2" Knob 1
69 50-569 Instruction Manual 1
70 50-777 Intelligate Control Board 1
ITEM PART # PART DESCRIPTION RAM 30
