1 Introduction
Congratulations on purchasing your CDA-VGA10 XGA Line Driver, which
is ideal for:
Dual monitor systems (local and remote)
Presentation systems: for remote transmission and cable equalization
The package includes the following items:
CDA-VGA10 XGA Line Driver
Power adapter (12V DC input) and this user manual
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
3 Overview
The CDA-VGA10 XGA Line Driver is a high performance line driver for
VGA/XGA signals that:
Accepts one input, provides correct buffering and isolation, and then
loops it out to a local monitor (or some other acceptor), as well as outputting
an amplified and equalized signal to a remote acceptor
Can drive very long high resolution lines 1 due to its large bandwidth that
exceeds 480MHz. This ensures that it remains transparent even at highest
resolution QXGA modes
In particular, the
CDA-VGA10 XGA Line Driver includes:
A TERM switch for input signal termination
Cable equalization control
ID Bit control (via a switch on its underside)
To achieve the best performance:
Connect only good quality connection cables, thus avoiding interference,
deterioration in signal quality due to poor matching, and elevated noise-
levels (often associated with low quality cables)
1 Up to 100 meters (300ft.) when using good quality cable
