Printhead
Printhead release
Paper guide
Paper spindle
Label roll
Drive roller
1
2
3
ON/OFF switch
Loading Media:
1
2
Outward Wound
Inward Wound
For direct thermal printers (DBDxx-xxxx-xxx), go to the “Connecting Data Cable” section of this Guide.
For thermal transfer printers (DBTxx-xxxx-xxx), proceed to the “Loading Ribbon” section of this Guide.
Thermal Transfer (TT) model shown. Printer is shown
with media cover removed for clarity
Loading Ribbon (Thermal Transfer Printers):
2
Unlatch Printhead
NOTE: Text on the ribbon leader should
be face down in front of the printer.
1
