7
Component (DT & TT Models) Function
A - Printhead Printing mechanism
B - Platen Roller Friction feed printing surface
C - Printhead Latches Latches for printhead mechanism
D - Media Guide & Spindle Holds and guides label roll
Components for Thermal Transfer Models
Component (TT Models) Function
E - Ribbon Take-up Driver Ribbon take-up core mount and driver
F - Ribbon Take-up Mount Flexible arm for ribbon take-up core mounting
G - Ribbon Supply Core Mounts Holds ribbon supply roll
G
E
F
