Connecting Data Cable:
I O I O COM/SER
Power OFF
Serial
(DB9)
ETHERNET
Power OFF
Ethernet
Power OFF
Parallel
(Centronics)
PARALLEL
Advantage LX Communication Interfaces:
2” 4”
KEY
DC SERIAL 9-PIN ETHERNET CENTRONICS
(DTE Device) Parallel 1284-B
NOTE: Interfaces shown apply to Advantage LX printers with S/N’s starting with “L”
