Bulletin 639510 May 2005 B-1
Appendix B
Antennas For ATC200-Lite Series System
The following table is an example of antenna models compatible for use with the ATC200-Lite
series Teletilt ® system. As new models become available for use with this system, updates will
be made to the ATC200-Lite controller software. Registered user’s are notified via e-mail of
updates. Updates can be downloaded from the Andrew web site. Contact Andrew’s technical
support at 800/676-5342 or 214/631-0310 for inquiries relating to the ATC200-Lite software.
Antenna Model Downtilt Range
ADFD0820-65A-R2DM 0°–15° (LB) / 0°–8° (HB)*
ADFD0920-65A-R2DM 0°–15° (LB) / 0°–8° (HB)*
ADFD0920-65B-R2DM 0° – 10°
ADFD0920-65C-R2DM 0°–8° (LB) / 0°–10° (HB)*
ADFD1820-33B-R2DM 0° – 7°
ADFD1820-65B-R2DM 0° – 7°
ADFD1820-65C-R2DM 0° – 5°
ADFD1820-90B-R2DM 0° – 7°
ADFD182A-65B-R2DM 2° – 10°
ADFDP182-65B-R2DM 0° – 7°
CTSDG-06513-R2DM 0° – 15°
UMWD-03319-R2DM 0° – 7°
UMWD-04517-R2DM 0° – 7°
UMWD-06513-R2DH 0° – 14°
UMWD-06516-R2DH 0° – 7°
UMWD-06516A-R2DH 2° – 10°
UMWD-06517-R2DH 0° – 5°
UMWD-09014-R2DH 0° – 7°
UMWD-09014B-R2DH 0° – 8°
UMWD-09016-R2DH 0° – 5°
UMWDP-06516-R2DH 0° – 7°
926LG65R2E-B 0° – 15°
932LG65R2E-B 0° – 8°
932QLG65R2EB 0° – 8°
936LG65R2E-B 0° – 6°
ATFDB-6565A-R2DM 0°–14° (LB) / 0°–7° (HB)*
ATFDA-6565B-R2DM 0° – 10°
ATFDA-6565C-R2DM 0°–8° (LB) / 0°–10° (HB)*
*LB = Low Band and HB = High Band for dual band antennas.
The ATC200-Lite program displays the antenna model numbers without the mounting hardware designator
“H” or “M” (see Section 5, Step 4 and Figure 5-2) and includes models compatible with the ATM200 actuator.
Antenna Model Downtilt Range
ADFD0820-6565A-XDM 0°–15° (LB) / 0°–8° (HB)*
ADFD0920-6565A-XDM 0°–15° (LB) / 0°–8° (HB)*
ADFD0920-6565B-XDM 0° – 10°
ADFD0920-6565C-XDM 0°–8° (LB) / 0°–10° (HB)*
ADFD1820-3333B-XDM 0° – 7°
ADFD1820-6565B-XDM 0° – 7°
ADFD1820-6565C-XDM 0° – 5°
ADFD1820-9090B-XDM 0° – 7°
ADFD182A-6565B-XDM 2° – 10°
ADFDP182-6565B-XDM 0° – 7°
CTSDG-06513-XDM 0° – 15°
UMWD-03319-XDM 0° – 7°
UMWD-04517-XDM 0° – 7°
UMWD-06513-XDH 0° – 14°
UMWD-06516-XDH 0° – 7°
UMWD-06516A-XDH 2° – 10°
UMWD-06517-XDH 0° – 5°
UMWD-09014-XDH 0° – 7°
UMWD-09014B-XDH 0° – 8°
UMWD-09016-XDH 0° – 5°
UMWDP-06516-XDH 0° – 7°
926LG65VTE-B 0° – 15°
932LG65VTE-B 0° – 8°
932QLG65VTEB 0° – 8°
936LG65VTE-B 0° – 6°
ATFDB-6565A-XDM 0°–14° (LB) / 0°–7° (HB)*
ATFDA-6565B-XDM 0° – 10°
ATFDA-6565C-XDM 0°–8° (LB) / 0°–10° (HB)*
Antennas With Factory Installed ATM200 Antennas Compatible With ATM200
