ATC200-Lite Teletilt ® Remote Control Downtilt System Section 4–Device Discovery and Addressing
Bulletin 639510 May 2005 4-5
3. A message will appear that the device was successfully removed from the address it
originally held. Click ‘OK’ to return to the ‘Manual Addressing’ screen (Figure 4-7).
4. To assign a specific address that is known to be available, follow steps 6 through 10.
To have the program suggest the first available address, click ‘Close’ to return to the ‘De-
vice Information’ list on the main screen and follow steps 5 through 10 (Figure 4-8).
Click ‘OK’.
Figure 4-7. Confirmation of Device Removal.
Click ‘Close’.
Figure 4-9. Selecting the Device to be Readdressed.
Figure 4-8. Exiting ‘Manual Addressing’ Screen.
1. Click on device to be readdressed (now addressed at 0).
2. Go to ‘Tools, Addressing’.
5. S e l e c t t h e d e v i c e f r o m t h e
‘Device Information’ list and
go to ‘Tools, Addressing . . .’
(Figure 4-9).
