2.4. Functional Description
Power : Power input for supplying 12V DC, 1A power.
Caution :
If MDC4050IR is powered by PoE, do not plug in DC Jack with active DC
power into DC power connector.
Network connector
100Mbps Ethernet connector (RJ-45) with PoE standard (802.3af). LED on the Ethernet connector shows
the status of MDC4050IR as the followings:
- Link LED (Orange)
It will be lit with orange color when network cabling is all right. Blinking orange color indicates that
normal data transmission is under way. Off state indicates that there is trouble in network connection.
Status LED
It will be lit in green or red depending on the status.
① Green : Green color indicates that the camera is in normal operation mode. Continuous green
indicates that data transmission is possible. Blinking green means that someone is connected to
MDC4050IR.
② Red : Continuous or blinking red indicates that hardware is in abnormal condition.
Micro SD card slot
Please insert SD memory card when you want to use SD memory card. In case of pulling out SD memory
card, please push the SD card.
MIC/Line Input
Connect external audio source or microphone.
Line Output
Connect speakers with built in amplifier. Audio from remote site is output through Line out in bi-directional
audio mode.
LED will be lit with red momentarily and it will be lit with green after a while when power is
applied into MDC4050IR
