Rev.1.0 (Dec. 2013) 7
External Terminals
LAN 10/100BaseT LAN (auto MDIX)
Analog output 1 channel D1 CVBS output of the encoding video
Alarm input / output Alarm I/O (1 Sensor input & 1 Relay output)
Factory Reset Supported
other MIC, Line in / Line out / 12VDCin
Installation
Standard PoE (IEEE802.3af) Supported
System Integration
Intelligent Video Motion Detection + IVS module(option)
Alarm Triggers Intelligent Video + Sensor Input
Alarm Events
video file upload(FTP), still Image(Email),
PTZ presets, Relay output
Video Buffer 00 sec Pre-alarm & 00 sec Post-alarm
Client Software
NVR-Pro 64ch@D1(free of charge)
Operating Environment, Power, Dimensions
Operating Temperature 0 C ~ 45C (32F~113F)
Operating Humidity 8~80% RH
Power 12V DC, 1A
Approvals FCC, CE, MIC, RoHS
Package information
IP camera, CD (User’s guide, Software…), L wrench, Ceiling mount, Screws,
DC power adaptor (Option)
