Page 22
Specifications
Input Impedance 2.4k
Ω
Differential
Output Impedance
Balanced 50
Ω
Pre-Amp Out 560
Ω
Max Input Level
Mic Level -23 dBV
Line Level +16 dBV
Max Output Level +19 dBV
Nominal Output Level
at 0 dB on Meter
Pre-amp Out -10 dBV
Balanced -60 dBV to +4 dBV (Level set on front panel)
Frequency Response 20Hz to 20kHz
THD+N -70 dB
Max NOMA Attenuation 20 dB
Phantom Power +48V
Power Supply 15Vdc 3.4A External Power Supply with
2.1mm connector.
Notes:- +ve connected to centre pin
–ve is connected to chassis ground
internally
Operating Temperature 0
°
to 40
°
C
Dimensions W483mm x D215mm x H44mm
Weight 2.2kg approx
