External Control Port
Pin Number
Function
1
Control Out 1
2
Control Out 3
3
Control Out 5
4
Control Out 7
5
Control In 8
6
Control In 6
7
Control In 4
8
Control In 2
9
Gnd (Chassis)
10
+5V Output ( 100mA Max )
11
VCA 1 Wiper
12
VCA 2 Top
13
VCA 2 Gnd (Chassis)
14
Control Out 2
15
Control Out 4
16
Control Out 6
17
Control Out 8
18
Control In 7
19
Control In 5
20
Control In 3
21
Control In 1
22
Gnd (Chassis)
23
VCA 1 Top
24
VCA 1 Gnd (Chassis)
25
VCA 2 Wiper
