DIN R AIL A MPLIFIER , MWI-13262 U LTRA S ERIES MAN-13262 U LTRA R EV BA
Appendix B. C
ABLE
G
LANDS
Several manufacturers provide cable glands that can be used to ensure the integrity of the EMC requirements when
installing this equipment in the enclosure. The objective of the cable gland is to provide a good mechanical entry
into the enclosure to protect the cable and also provide an electrical bond the outer shield (screen) of the cable to the
enclosure.
The following is a list of cable gland venders and the range of cable sizes that each vender can provide. This is not
an endorsement or promotion of any particular vender or manufacturer; the information is provided only to assist
you in the application of the product described in this document.
Cable Gland Vendor Cables
Sealcon
14853 E. Hinsdale Ave., Suite D
Englewood, CO 80112, U.S.A.
Tel: (303)699-1135 Fax: (303)680-5344
Tel: (800)456-9012
EMI-Proof Grounded Nickel Plated Brass Liquid Tight Strain
Relief Fittings
Standard and Feed-through types
Cable diameters from 0.11 inches to 1.38 inches
Metric (PG) or NPT thread types
Optional metric (PG) to NPT adapters
GlobTek, Inc.
186 Veterans Drive
Northvale, NJ 07647
Tel: (207)784-1000 Fax: (210)784-0111
Email: [email protected]
URL: www.globtek.com
Standard, IP68 protection
Index EMC Cable Glands
Cable diameters from 6.0 mm to 20.0 mm
Metric threads
Wiedmuller
Tel: (800)849-9343 Fax: (800)794-0252
Bulkhead Cable Glands for Braid/Armour Termination
Standard types KGC 1 Series
Cable diameters from 1.8 mm to 39.9 mm
Metric threads
Optional washers and locknuts
P AGE 26 OF 26
