MAN-70254R EV . AA U LTRA S ERIES U NDER P ILLOW B LOCK T RANSDUCER
P AGE 3 OF 18
T
ABLE OF
C
ONTENTS
1 I
MPORTANT
I
NFORMATION
.........................................................................5
1.1 O RDER N UMBERS ........................................................................................................... 5
1.2 C ONTACT I NFORMATION AND S ERVICE A SSISTANCE .......................................................... 5
1.3 R ECEIVING AND U NPACKING ............................................................................................ 6
1.4 P RE -I NSTALLATION P RECAUTIONS .................................................................................... 6
1.4.1 Shipping.................................................................................................................. 6
1.4.2 Roll Balance............................................................................................................ 6
1.4.3 Critical Roll Speed................................................................................................... 7
1.4.4 Avoiding Damage to the Roll ................................................................................... 7
1.4.5 Excitation Voltage ................................................................................................... 7
2 S
PECIFICATIONS
.......................................................................................8
2.1 F ORCE R ATINGS ............................................................................................................. 9
2.2 B EFORE I NSTALLING THE T RANSDUCER ............................................................................ 9
2.2.1 Installation Precautions ........................................................................................... 9
2.2.2 Safety Considerations ............................................................................................. 9
2.2.3 Mounting Configurations ....................................................................................... 10
2.2.4 Mounting Hardware and Fastener Torque Recommendations .............................. 11
2.2.5 Mounting Dimensions............................................................................................ 12
3 I
NSTALLING THE
U
NDER
P
ILLOW
B
LOCK
T
RANSDUCER
..............................13
3.1 O RIENTING T HE U NDER P ILLOW B LOCK T RANSDUCER ..................................................... 13
3.2 M OUNTING S URFACE P REPARATION ............................................................................... 13
3.3 M OUNTING THE T RANSDUCER TO THE M ACHINE F RAME ................................................... 13
3.4 M OUNTING THE P ILLOW B LOCK B EARING TO THE L OAD C ELL ........................................... 14
3.5 E XTREMELY S EVERE A PPLICATIONS ............................................................................... 14
3.6 S HAFT E XPANSION ........................................................................................................ 15
3.7 M OUNTING THE S ENSING R OLL ...................................................................................... 15
3.8 C HECKING T HE T RANSDUCER M OUNTING ....................................................................... 15
3.9 E LECTRICAL C ONNECTIONS AND W IRING ........................................................................ 15
3.10 M ATING C ONNECTORS ............................................................................................... 16
3.11 C ALIBRATION ............................................................................................................. 16
4 T ROUBLE S HOOTING ...............................................................................17
4.1 DC R ESISTANCE C HECK ................................................................................................ 18
4.2 DC V OLTAGE AND C URRENT C HECKS ............................................................................ 18
