5
DETHATCHER OR ROLLER
PLUG OR SPIKE AERATOR
fIGure 8
Attach the center brace to the bottom of the tray to 15.
use the plug or spike aerator. Attach the center brace
to the front of the tray to use the dethatcher or roller, .
Tighten the bolts. See figure 8.
Attach the lower lift tubes (19) to the lift tube assembly 12.
using two 5/16 x 1-1/2" hex bolts (10) and 5/16" nylock
nuts (14). See figure 6.
Tighten.
fIGure 7
fIGure 6
1
13
7
12
Attach the lift tube assembly (2) and the hitch tube 10.
(5) to the rear hole on the left side of the tray using a
5/16 x 1-1/2" hex bolt (10) and 5/16" nylock nut (14).
Tighten the nut then loosen 1/2 turn.
Tighten
11. the nuts and bolts shown in figures 2 and 3.
fIGure 5
14
10
2
5
Attach the wheels (1) to the lift tube assembly using 13.
a 1/2 x 4" hex bolt (7), a 1/2" jam nut (13) placed
between the wheel and the lift tube assembly and 1/2"
a nylock jam nut (12) for each wheel. See figure 7.
Tighten
14. the 1/2" jam nut and 1/2" nylock jam nut so
that the wheel turns freely on the hex bolt.
14
19
10
