33
APPENDIX B: Technical Features
Physical Interface
- 1 Electrical Power plug
- 1 RJ45 for 10/100 Ethernet (AutoMDI/MDI-X)
- 2 Push Botton (SYNC and Reset)
- LEDs: (DECT1.0, Power, PLC Link status, Ethernet)
Chipset
- Chipset: Intellon INT6400® Integrated Single-chip Powerline Network Transceiver
Frequency Band
- 2Mhz to 30Mhz band
Modulation Support
- OFDM, 1155 carriers, 1024/256/64/16/8 QAM, QPSK, BPSK and ROBO Modulation
Scheme
Protocol/Standard
- HomePlug AV 1.0 specification, IEEE 802.3 10/100 Ethernet (100Mbps) and
IEEE 802.3u Fast Ethernet Compliant
- 10/100 Mbps AutoMDI/MDIx Support
- Co-exists with existing 14Mbps HomePlug 1.0 and 85Mbps Turbo HomePlug 1.0
Security
- 128-bit AES Encryption with key management for secure powerline
communications (Utilise SYNC Button or Utility for Windows 2000, ME, XP, Vista to
enable encryption)
- Rotating NEK (Network Encryption Key) and NMK
Data Rate/Range
- Throughput=Up to 200Mbps* / Range=Up to 200mt*
Power Supply
- Switch Mode 100V-240V Supply
- Protection: OCP, OVP, SCP
QoS
- TDMA channel access with Contention–Free and Contention-Based (CSMA/CA) period
- Channel Adaptation ensures that signal integrity is maintained even
under harsh noise environment
- Four Level prioritized random access method based on contention access
and multi-segment
