connect button will indicate with a message "NO HOMEPLUG ADAPTERS
DETECTED".
The bottom window panel displays all the HomePlug remote devices that are detected
on the current network. The total number of remote devices connected on the same
network can be found on top of the Remote device panel. Within this panel, you can
also find some useful informations of each remote device such as its password, the
connection quality, transfer rate and MAC address.
The Network type (Public or Private) is also displayed based on the network status
of the local device. The scan status option is displayed on the top right corner above
the Remote devices panel showing whether the Autoscan function is turned ON or
OFF.
The following information is displayed for all devices that appear in the lower panel:
Device Name: Show the default device name. User can change the name
by either clicking on the Rename button or by clicking on the name and
editing in-place. An icon is usually shown with the device name.
Password (*required when one needs to change the Private Network
Name of the devices) This column is left blank by default. The password
will be displayed only after it has been entered. For detail information on
password setup, please refer to section on Password Setup
Instruction. Each device comes with a unique password and it can be
found at the back of the device itself.
Rate (Mbps): Display the data transmission rate of each device.
MAC Address: Show the Remote device MAC address.
Quality: Display the overall quality of the data transmission rate. When
the transmission rate is good, the number of line appear will increase.
